CZone Touch 5 - 5 Specifications; Technical Specifications; Dimensions; Figure 9. Dimensions

27
EN / CZone Touch 5 User & Installation Manual
5 Specifications
5.1 Technical Specifications
Model
Touch 5
Article number
80-911-0124-00
Casing
PCB/ABS
Display Type
WVGA Colour TFT LCD
Display Resolution
480 x 800 pixels (H x W)
Screen Brightness
1200 nits
Operating
Temperature
-15°C to +55°C (+5°F to +131°F )
Water Ingress
IPX6 and 7
Operating Voltage
10 – 17V DC
Power Consumption
900mA @ 13.5V
Processor
iMX61 single core
Weight (excluding
mounting hardware)
526 grams (1.16lbs)
Conformity
CE, C-Tick
5.2 Dimensions
Figure 9. Dimensions
58 [2 1/4"]
80 [3 3/16"]
8 [5/16"]
152 [6"]
120 [4 3/4"]
