5. 12 V DC supply
6. NMEA 2000 cable and connector
Connect Red to (+) DC using a 3 amp fuse. Connect Black to (-) DC.
2.4 Power Control Connection
The yellow Power Control wire in the power cable is an input that will turn on the unit when power is
applied.
2.4.1 Power Control Unconnected
Device will turn on when the power button on the front of the unit is pressed. Leave the yellow Power
Control wire disconnected and tape or heat-shrink the end to prevent shorting.
2.4.2 Power Control To Supply Positive (Auto On)
Device will turn on immediately when power is applied. Common the yellow wire with the red wire
after the fuse.
2.5 NMEA 2000 Backbone
Run an NMEA2000 cable from the NMEA2000 connector to an NMEA2000 network backbone
