CZone Touch 5 - In the Box; Card Reader

EN / CZone Touch 5 User & Installation Manual
6
1.2.3 In The Box
1.2.4 Card Reader
Used for attaching a microSD memory card. The memory card can be used for software updates. The
card reader door is opened by pulling the rubber cover open. The card reader door should always be
securely shut immediately after inserting or removing a card, in order to prevent possible water
ingress.
1
2
3
5
4
1. Touch 5
2. Sun Cover
3. Panel mount gasket
4. Power/NMEA cable
5. Panel mount screws
