DAP-1360 Wireless N300 Access Point & Router
User Manual
Configuring Device (Router Mode)
Figure 75. Configuring Static IP WAN connection. The expert settings mode. The Miscellaneous section.
Parameter Description
Miscellaneous
Isolate connection
When the checkbox is selected, the access point uses an alternate
routing table for this connection. Select the checkbox only when
your ISP requires this.
Enable RIP
Select the checkbox to allow using RIP for this connection.
Enable IGMP Multicast
Select the checkbox to allow multicast traffic from the external
network (e.g. video streaming) to be received.
NAT
Select the checkbox if you want one WAN IP address to be used for
all computers of your LAN.
Firewall
Select the checkbox to enable protection against ARP and DDoS
attacks.
Ping
Select the checkbox to allow the access point to answer ping
requests from the external network through this connection. For
security reasons, it is recommended not to select this checkbox.
Click the Next button to continue.
After that the page displaying all specified settings opens. Click the Apply button to create the
connection or the Back button to specify other settings.
After clicking the Apply button, the page for checking the Internet availability opens (see the
Checking Internet Availability section, page 144).
Page 105 of 270
