D-Link DAP-1360 User Manual

DAP-1360 Wireless N300 Access Point & Router
User Manual
Configuring Device (Router Mode)
Creating PPTP + Dynamic IP or L2TP + Dynamic IP WAN Connection
To create a connection of the PPTP + Dynamic IP or L2TP + Dynamic IP type, click the Add button
on the Net / WAN page. On the opened page, select the relevant value from the Connection
Type drop-down list and specify the needed values.
Figure 161. The page for creating a new connection. The General settings section.
Parameter Description
General settings
Interface A physical interface to which the new connection will be assigned.
Name A name for connection for easier identification.
Enable Select the checkbox to enable the connection.
Direction The direction of this connection.
Page 201 of 270

D-Link DAP-1360 Specifications

Power

power input	5V DC/1.2 A
power adapter socket	external power adapter

Operating Environment

operating temperature	0 ˚C to 55 ˚C
storage temperature	10 ˚C to 70 ˚C
operating humidity	10% to 90% non-condensing

Weight and Dimensions

weight	215 grams
dimensions	147.5 x 113 x 31.5 mm
