D-Link DAP-1360 User Manual

DAP-1360 Wireless N300 Access Point & Router
User Manual
Overview
Back Panel
Figure 2. Back panel view.
Name Description
WPS
RESET
A button to restore the factory default settings and to quickly add
wireless devices to the access point's WLAN (the WPS function).
To use the WPS function: with the device turned on, push the button,
hold it for 2 seconds, and release. The WPS LED should start
blinking.
To restore the factory defaults: with the device turned on, push the
button, hold it for 10 seconds, then release it.
INTERNET
A port to connect to a cable or DSL modem or to a private Ethernet
line (it is recommended to use the cable included in the delivery
package).
LAN An Ethernet port to connect to a computer.
12 VDC IN Power connector.
ON/OFF A button to turn the access point on/off.
The device is also equipped with two external Wi-Fi antennas.
Page 11 of 270

D-Link DAP-1360 Specifications

Power

power input	5V DC/1.2 A
power adapter socket	external power adapter

Operating Environment

operating temperature	0 ˚C to 55 ˚C
storage temperature	10 ˚C to 70 ˚C
operating humidity	10% to 90% non-condensing

Weight and Dimensions

weight	215 grams
dimensions	147.5 x 113 x 31.5 mm
