D-Link DAP-1360 User Manual

DAP-1360 Wireless N300 Access Point & Router
User Manual
Overview
Specifications
*
Hardware
WAN Interface
• 1 10/100BASE-TX Ethernet port for cable or DSL modem or private Ethernet line
LAN Interface
• 1 10/100BASE-TX Ethernet port
WLAN Interface
• IEEE 802.11n (up to 300Mbps) • IEEE 802.11b/g
Antenna
• Two 5dBi detachable
omnidirectional antennas
• RP-SMA connector
Frequency Range
• 802.11b
◦ 2400 ~ 2497MHz ISM band
• 802.11g
◦ 2400 ~ 2483.5MHz ISM band
• 802.11n
◦ 2400 ~ 2483.5MHz ISM band
Data Rate
• 802.11b
◦ 11, 5.5, 2, and 1Mbps
• 802.11g
◦ 54, 48, 36, 24, 18, 12, 9, and 6Mbps
• 802.11n
MCS
GI3=800ns GI=400ns
20MHz
(Mbps)
40MHz
(Mbps)
20MHz
(Mbps)
40MHz
(Mbps)
0 6,5 13,5 7,2 15
1 13 27 14,4 30
2 19,5 40,5 21,7 45
3 26 54 28,9 60
4 39 81 43,3 90
5 52 108 57,8 120
6 58,5 121,5 65 135
7 65 135 72,2 150
8 13 27 14,4 30
9 26 54 28,9 60
10 39 81 43,3 90
11 52 108 57,8 120
12 78 162 86,7 180
13 104 216 115,6 240
14 117 243 130 270
15 130 270 144,4 300
Modulation Schemes
• 802.11b: DQPSK, DBPSK, DSSS,
CCK
• 802.11g: BPSK, QPSK, 16QAM,
64QAM with OFDM
• 802.11n: BPSK, QPSK, 16QAM,
64QAM with OFDM
* The device features are subject to change without notice. For the latest versions of the firmware and relevant
documentation, visit www.dlink.ru.
Page 7 of 270

D-Link DAP-1360 Specifications

Power

power input	5V DC/1.2 A
power adapter socket	external power adapter

Operating Environment

operating temperature	0 ˚C to 55 ˚C
storage temperature	10 ˚C to 70 ˚C
operating humidity	10% to 90% non-condensing

Weight and Dimensions

weight	215 grams
dimensions	147.5 x 113 x 31.5 mm
