D-Link DAP-1360 User Manual

DAP-1360 Wireless N300 Access Point & Router
User Manual
Overview
Transmitter Output Power
The maximum value of the transmitter
output power depends upon the radio
frequency regulations applied in your
country
• 802.11b (typical at room temperature 25 °C)
◦ 17dBm (±1.5dB) at 1, 2, 5.5, 11Mbps
• 802.11g (typical at room temperature 25 °C)
◦ 17dBm (±1.5dB) at 6Mbps
◦ 17dBm (±1.5dB) at 9Mbps
◦ 17dBm (±1.5dB) at 12Mbps
◦ 16dBm (±1.5dB) at 18Mbps
◦ 16dBm (±1.5dB) at 24Mbps
◦ 15dBm (±1.5dB) at 36Mbps
◦ 15dBm (±1.5dB) at 48Mbps
◦ 15dBm (±1.5dB) at 54Mbps
• 802.11n (typical at room temperature 25 °C)
HT-20 HT-40
16.5dBm (±1.5dB) at
MCS0/8
16.5dBm (±1.5dB) at
MCS0/8
16.5dBm (±1.5dB) at
MCS1/9
16.5dBm (±1.5dB) at
MCS1/9
16.5dBm (±1.5dB) at
MCS2/10
16.5dBm (±1.5dB) at
MCS2/10
16dBm (±1.5dB) at
MCS3/11
16dBm (±1.5dB) at
MCS3/11
16dBm (±1.5dB) at
MCS4/12
16dBm (±1.5dB) at
MCS4/12
15.5dBm (±1.5dB) at
MCS5/13
15.5dBm (±1.5dB) at
MCS5/13
15dBm (±1.5dB) at
MCS6/14
15dBm (±1.5dB) at
MCS6/14
14dBm (±1.5dB) at
MCS7/15
14dBm (±1.5dB) at
MCS7/15
Receiver Sensitivity
• 802.11b (typical at PER = 8% (1000-byte PDUs))
◦ -82dBm at 1Mbps
◦ -80dBm at 2Mbps
◦ -78dBm at 5.5Mbps
◦ -76dBm at 11Mbps
• 802.11g (typical at PER = 10% (1000-byte PDUs))
◦ -85dBm at 6Mbps
◦ -84dBm at 9Mbps
◦ -82dBm at 12Mbps
◦ -80dBm at 18Mbps
◦ -77dBm at 24Mbps
◦ -73dBm at 36Mbps
◦ -69dBm at 48Mbps
◦ -68dBm at 54Mbps
• 802.11n (typical at PER = 10% (1000-byte PDUs))
HT-20 HT-40
-82dBm at MCS0/8 -79dBm at MCS0/8
-79dBm at MCS1/9 -76dBm at MCS1/9
-77dBm at MCS2/10 -74dBm at MCS2/10
-74dBm at MCS3/11 -71dBm at MCS3/11
-70dBm at MCS4/12 -67dBm at MCS4/12
-66dBm at MCS5/13 -63dBm at MCS5/13
-65dBm at MCS6/14 -62dBm at MCS6/14
-64dBm at MCS7/15 -61dBm at MCS7/15
Software
Operation Modes
• Access point mode • Router mode
Page 8 of 270

D-Link DAP-1360 Specifications

Power

power input	5V DC/1.2 A
power adapter socket	external power adapter

Operating Environment

operating temperature	0 ˚C to 55 ˚C
storage temperature	10 ˚C to 70 ˚C
operating humidity	10% to 90% non-condensing

Weight and Dimensions

weight	215 grams
dimensions	147.5 x 113 x 31.5 mm
