DAP-1360 Wireless N300 Access Point & Router
User Manual
Configuring Device (Router Mode)
Figure 91. Configuring Dynamic IP + PPPoE WAN connection. The expert settings mode.
The Miscellaneous section.
Parameter Description
Miscellaneous
Enable RIP
Select the checkbox to allow using RIP for this connection.
Enable IGMP Multicast
Select the checkbox to allow multicast traffic from the external
network (e.g. video streaming) to be received.
NAT
Select the checkbox if you want one WAN IP address to be used for
all computers of your LAN.
Firewall
Select the checkbox to enable protection against ARP and DDoS
attacks.
Ping
Select the checkbox to allow the access point to answer ping
requests from the external network through this connection. For
security reasons, it is recommended not to select this checkbox.
Click the Next button to continue.
Page 122 of 270
