DAP-1360 Wireless N300 Access Point & Router
User Manual
Configuring Device (Router Mode)
Figure 159. The page for creating a new connection. The IP section.
Parameter Description
IP
IP Address
Enter an IP address for this WAN connection.
Netmask
Enter a subnet mask for this WAN connection.
Gateway IP address
Enter an IP address of the gateway used by this WAN connection.
Primary DNS server/
Secondary DNS server
Enter addresses of the primary and secondary DNS servers in the
relevant fields.
Isolate connection
When the checkbox is selected, the access point uses an alternate
routing table for this connection. Select the checkbox only when
your ISP requires this.
Enable RIP Select the checkbox to allow using RIP for this connection.
Enable IGMP Multicast
Select the checkbox to allow multicast traffic from the external
network (e.g. video streaming) to be received.
NAT
Select the checkbox if you want one WAN IP address to be used for
all computers of your LAN.
Firewall
Select the checkbox to enable protection against ARP and DDoS
attacks.
Ping
Select the checkbox to allow the access point to answer ping
requests from the external network through this connection. For
security reasons, it is recommended not to select this checkbox.
Page 197 of 270
