DAP-1360 Wireless N300 Access Point & Router
User Manual
Configuring Device (Router Mode)
Figure 163. The page for creating a new connection. The IP section.
Parameter Description
IP
Obtain DNS server
addresses
automatically
Select the checkbox to configure automatic assignment of DNS
server addresses. If the checkbox is selected, the Primary DNS
server and Secondary DNS server fields are not displayed.
Primary DNS server/
Secondary DNS server
Enter addresses of the primary and secondary DNS servers in the
relevant fields.
Vendor ID The identifier of your ISP. Optional.
Hostname A name of the access point specified by your ISP. Optional.
Isolate connection
When the checkbox is selected, the access point uses an alternate
routing table for this connection. Select the checkbox only when
your ISP requires this.
Enable RIP Select the checkbox to allow using RIP for this connection.
Enable IGMP Multicast
Select the checkbox to allow multicast traffic from the external
network (e.g. video streaming) to be received.
NAT
Select the checkbox if you want one WAN IP address to be used for
all computers of your LAN.
Firewall
Select the checkbox to enable protection against ARP and DDoS
attacks.
Ping
Select the checkbox to allow the access point to answer ping
requests from the external network through this connection. For
security reasons, it is recommended not to select this checkbox.
Page 203 of 270
