Configuring Device (Router Mode)
To activate the WPS function, select the WPS Enable checkbox and click the Apply button. When
the checkbox is selected, the Information and Connection sections are available on the page.
Parameter Description
Default PIN code
The PIN code of the access point. This parameter is used when
connecting the access point to a registrar to set the parameters of the
WPS function.
WPS Status
The state of the WPS function:
• Configured (all needed settings are specified; these settings
will be used upon establishing the wireless connection)
• Unconfigured (after activating the WPS function, the SSID
and the encryption key will be configured automatically, the
network authentication type will be changed to WPA2-PSK).
SSID
The name of the access point's WLAN.
Network Authentication The network authentication type specified for the WLAN.
Encryption
The encryption type specified for the WLAN.
Encryption key The encryption key specified for the WLAN.
Refresh
Click the button to refresh the data on the page.
Reset to unconfigured Click the button to reset the parameters of the WPS function.
WPS Method
A method of the WPS function. Select a value from the drop-down
list.
PIN: Connecting the device via the PIN code.
PBC: Connecting the device via the push button (actual or virtual).
PIN Code
The PIN code of the WPS-enabled device that needs to be connected
to the wireless network of the access point.
The field is displayed only when the PIN value is selected from the
WPS Method drop-down list.
Connect
Click the button to connect the wireless device to the access point's
WLAN via the WPS function.
