DAP-1360 Wireless N300 Access Point & Router
User Manual
Configuring Device (Router Mode)
Parameter Description
TX Power The transmit power (in percentage terms) of the access point.
Drop multicast
Select the checkbox to disable multicasting for the access point's
WLAN. Deselect the checkbox to enable multicasting from WAN
connections for which the Enable IGMP Multicast checkbox is
selected.
Bandwidth
The channel bandwidth for 802.11n devices.
20MHz: 802.11n devices operate at 20MHz channels.
40MHz: 802.11n devices operate at 40MHz channels.
20/40MHz -: 802.11n devices operate at 20MHz and 40MHz
channels (the channel is combined with the previous adjacent
channel).
20/40MHz +: 802.11n devices operate at 20MHz and 40MHz
channels (the channel is combined with the next adjacent channel).
Short GI
Guard interval (in nanoseconds). This parameter defines the interval
between symbols transmitted when the access point is
communicating to wireless devices.
Enable: the access point uses the 400 ns short guard interval. For
the wireless network operating modes which support 802.11n
standard only (see the value of the Wireless mode drop-down list
on the Wi-Fi / Basic settings page).
Disable: the access point uses the 800 ns standard guard interval.
When you have configured the parameters, click the Apply button.
