DAP-1360 Wireless N300 Access Point & Router
User Manual
Configuring Device (Router Mode)
Parameter Description
Source IP address
The source host/subnet IP address.
To choose a device connected to the LAN of the access point at the
moment, select the relevant IP address from the drop-down list (the
field will be filled in automatically).
If you want to specify a range of IP addresses, click the icon
(Range) and enter the starting and ending addresses in the left and
right fields correspondingly.
Destination IP address
The destination host/subnet IP address.
To choose a device connected to the LAN of the access point at the
moment, select the relevant IP address from the drop-down list (the
field will be filled in automatically).
If you want to specify a range of IP addresses, click the icon
(Range) and enter the starting and ending addresses in the left and
right fields correspondingly.
Ports
Source port
A port of the source IP address. You can specify one port, several
ports separated by a comma, or a range of ports separated by a colon.
Destination port
A port of the destination IP address. You can specify one port,
several ports separated by a comma, or a range of ports separated by
a colon.
Click the Apply button.
To edit a rule for IP filtering, click the link to the relevant rule. On the opened page, change the
needed parameters and click the Apply button.
To remove a rule, select the checkbox located to the left of the relevant line in the table and click
the Delete button. Also you can remove a rule on the editing page.
To remove all rules from this page, click the Clear all button (the button is displayed if at least one
rule exists).
