D-Link DAP-1360U

DAP-1360U Wireless N300 Access Point & Router
User Manual
Configuring via Web-based Interface
Figure 61. The page for creating a new PPPoE connection. The Miscellaneous section.
Parameter Description
Miscellaneous
NAT
If the switch is moved to the right, the network address translation
function is enabled. Do not disable the function unless your ISP
requires this.
Firewall
If the switch is moved to the right, protection against external
connections for the LAN devices is enabled (for example, against
attempts to get information about the LAN devices or to hack a
device from the LAN). For security reasons, it is recommended not
to disable this function.
RIP
Move the switch to the right to allow using RIP for this connection.
Ping
If the switch is moved to the right, the access point responds to ping
requests from the external network through this connection. For
security reasons, it is recommended to disable this function.
Isolate connection
If the switch is moved to the right, the access point uses an alternate
routing table for this connection. Enable this function only when
your ISP requires this.
When all needed settings are configured, click the APPLY button.
After clicking the button, the window for creating an additional connection opens.
If your ISP offers access to local services (e.g. audio and video resources), select the existing
connection or select the create a new connection choice of the radio button. Then click the OK
button. On the page displayed, specify the parameters for the connection of the Dynamic IPv4 or
Static IPv4 type and click the APPLY button. Click the BACK button to specify other settings for
the connection of the PPPoE type.
If you do not need to create an additional connection, click the SKIP button. In this case, the
Connections Setup / WAN page opens.
Page 70 of 158
