32D-Link DAP-2690 User Manual
Section 3 - Conguration
VLAN Settings
The DAP-2690 supports VLANs. VLANs can be created with a Name and VID. Mgmt (TCP stack), LAN, Primary/Multiple SSID, and WDS connection
can be assigned to VLANs as they are physical ports. Any packet which enters the DAP-2690 without a VLAN tag will have a VLAN tag inserted with
a PVID. Once you have made the desired settings, click the Save button to let your changes take eect.
The VLAN List tab displays the current VLANs.
VLAN Status:
Click the Enable button. Next, go to the Add/Edit VLAN
tab to add or modify an item on the VLAN List tab.
The current VLAN mode is displayed.
VLAN Mode:
