71D-Link DAP-2690 User Manual
Section 4 - Using the AP Array
AP Roles in an Array
There are three modes for the administrator to dene the role of each AP.
• Master AP
The Master AP can do all the management settings for members in an array. Each array can only have one Master AP.
• Backup Master AP
In an event when the Master AP crashes, the Backup Master AP will take over the Master AP function. Each array can have up to two Backup
Master APs.
• Slave AP
The Slave AP follows all the settings in the Master AP.
AP Array Easy Conguration
The following section shows how simple it is to congure the D-Link AP Array for the dierent AP roles:
Master AP Role
Click Advanced Settings > AP Array to view and edit the information on the AP in an array.
Step 1:
Click Enable AP Array and select the Master role.
