72D-Link DAP-2690 User Manual
Section 4 - Using the AP Array
Step 2:
Set up the AP Array name and password. Click the Save button located on the lower right
hand side.
Note: Remember to select “Save & Activate”. The AP will not become master until you select “Save
& Activate”.
Slave AP Role
Click Advanced Settings > AP Array to view and edit the information on the AP in an array.
Step 1:
Click Enable AP Array and select the Slave role.
