DAP-600P Wireless AC2600 Wave 2 MU-MIMO Dual Band
PoE Access Point / Router
User Manual
Configuring via Web-based Interface
In the Wireless Networks section, the list of available wireless networks is displayed. To view
the latest data on available wireless networks, click the UPDATE LIST button.
To connect to a wireless network from the list, select the needed network. Move the Network
options switch to the right to view more detailed information on the network to which the access
point connects. If a password is required, enter it in the relevant field. Click the CONNECT button.
To connect to a hidden network, select the Connect to hidden network value from the
Connecting to network drop-down list. Enter the name of the network in the Network name
(SSID) field. If needed, fill in the BSSID field. Then select the needed type of authentication from
the Network authentication drop-down list.
When the Open or WEP authentication type is selected, the following settings are displayed on the
page:
Parameter Description
Enable encryption WEP
For Open authentication type only.
To activate WEP encryption, move the switch to the right. Upon that
the Default key ID drop-down list, the Encryption key WEP as
HEX switch, and four Encryption key fields are displayed on the
page.
Default key ID
The number of the key (from first to fourth) which will be used for
WEP encryption.
Encryption key WEP as
HEX
Move the switch to the right to set a hexadecimal number as a key
for encryption.
Encryption key
(1-4)
Keys for WEP encryption. The access point uses the key selected
from the Default key ID drop-down list. It is required to specify all
the fields. Click the Show icon ( ) to display the entered key.
Page 135 of 235
