DAP-600P Wireless AC2600 Wave 2 MU-MIMO Dual Band
PoE Access Point / Router
User Manual
Configuring via Web-based Interface
Creating Dynamic IPv4 or Static IPv4 WAN Connection
On the connection creation page, go to the All Settings tab. Then select the relevant value from
the Connection type drop-down list and specify the needed values.
Figure 77. The page for creating a new Static IPv4 connection. Selecting a connection type.
Parameter Description
Interface
The drop-down list is displayed if additional WAN interfaces are
specified in the system (see the VLAN section, page 159).
A physical or virtual WAN interface to which the new connection
will be assigned.
Enable connection
Move the switch to the right to enable the connection.
Move the switch to the left to disable the connection.
Connection name
Available for the advanced mode only.
A name for the connection for easier identification.
Page 91 of 235
