DES-1228/ME Layer 2 Metro Ethernet Switch CLI Reference Manual
251
38
LLDP COMMANDS
The LLDP commands in the Command Line Interface (CLI) are listed (along with the appropriate parameters) in the following
table.
Command Parameters
enable lldp
disable lldp
config lldp message_tx_interval <sec 5 - 32768 >
config lldp
message_tx_hold_multiplier
< int 2 - 10 >
config lldp tx_delay < sec 1 - 8192 >
config lldp reinit_delay < sec 1 - 10 >
config lldp notification_interval <sec 5 - 3600 >
config lldp ports [<portlist>|all] notification [enable | disable]
config lldp ports [<portlist>|all] admin_status [tx_only | rx_only | tx_and_rx | disable]
config lldp ports [<portlist>|all] mgt_addr ipv4 <ipaddr> [enable | disable]
config lldp ports [<portlist>|all] basic_tlvs [all | {port_description | system_name |
system_description | system_capabilities}] [enable | disable]
config lldp ports [<portlist>|all] dot1_tlv_pvid [enable | disable]
config lldp ports [<portlist>|all] dot1_tlv_vlan_name [vlan [all | <vlan_name 32> ] | vlanid
<vidlist> ] [enable | disable]
config lldp ports [<portlist>|all] dot1_tlv_ protocol_identity[all | { eapol | lacp | gvrp | stp }]
[enable | disable]
config lldp ports config lldp ports [<portlist>|all] dot3_tlvs [all | {mac_phy_configuration_status |
link aggregation | power_via_mdi | maximum_frame_size}] [enable | disable]
config lldp forward_message [enable | disable]
show lldp
show lldp mgt_addr {ipv4 <ipaddr>}
show lldp ports {<portlist>}
show lldp local_ports { <portlist>} {mode [brief | normal | detailed]}
show lldp remote_ports {<portlist>} {mode [brief | normal | detailed]}
show lldp statistics
show lldp statistics ports {<portlist>}
Each command is listed, in detail, in the following sections.
enable lldp
Purpose Used to enable LLDP operations on the switch.
Syntax
enable lldp
Description This is a global control for the LLDP function.
When this function is enabled, the switch can start to transmit LLDP packets and receive
