xStack DES-3528 Series Layer 2 Stackable Fast Ethernet Managed Switch User Manual
• Drop – Drops the packet.
Action
Conform – Specifies the action when the packet is in “green color” mode.
Exceed – Specifies the action when the packet is in “yellow color” mode.
Violate – Specifies the action when the packet is in “red color” mode.
• Permit – Permits the packet.
• Replace dscp – Change the dscp of the packet
• Permit – Permits the packet.
• Replace DSCP – Allows you to change the DSCP of the packet.
• Drop – Drops the packet.
• Permit – Permits the packet.
• Replace DSCP – Change the DSCP of the packet.
Click Apply to implement changes made, click Back to return to the ACL Flow Meter.
205
