52D-Link DIR-457U User Manual
Section 4 - Device Setup using D-Link Connection Manager (MAC OS)
Band Settings
The DIR-457U supports two band selection options:
Automatic - The DIR-457U automatically selects the band based on
the networks available in current area and those supported by the
DIR-457U.
UMTS/HSUPA Only - Restricts the DIR-457U to using 3G service on
UMTS/HSUPA bands.
GSM/GPRS/EDGE Only - Restricts the DIR-457U to using 2G
service on GSM/GPRS/EDGE bands.
To adjust the band settings follow the instructions below:
1. Click the Prole button.
2. Select Band tab.
3. Select Automatic, UMTS/HSUPA only, or GSM/GPRS/EDGE only.
4. Click Apply and OK.
Profile Settings
The Prole Settings page allows you to manually change your Band and Network setting in case your DIR-457U can not automatically
connect to your network provider.
