D-Link DSL-2600U - Page 70

Web Configuration
D-Link DSL-2600U User Manual
67
Mixed WPA2/WPA Authentication
This authentication mode means AP auto adjust to use WPA2 or WPA according to
wireless clients.
= Network Authentication: Select the authentication mode for the selected wireless
LAN of SSID to be Mixed WPA2/WPA.
= WPA2 Preauthentication: Selec Enable or Disenable.
= Network Re-auth Interval: Specifies the timer of re-authentication between the
server and the client.
= WPA Group Rekey Interval: Specifies the timer the WPA key must change. If the
value set 0, no need to change. The change is done automatically between the
server and the client.
= Radius Server IP Adress: Enter the IP Address of the authentication server.
= Radius Port: Enter the port number of the authentication server. The default port
number is 1812.
= Radius Key: Enter the same key as the Radius server’s.
= WPA Encryption: Select TKIP, AES or TKIP + AES. The AES is default. The TKIP +
AES encryption mode means AP auto adjust to use TKIP or AES according to
wireless clients.
Click Save/Apply to save the wireless security options and make the modification effect.
WPA-PSK Authentication
= Network Authentication: Select the authentication mode for the selected wireless
LAN of SSID to be Mixed WPA-PSK.
= WPA Pre-Shared Key: Enter the pre-shared key for WPA. Client stations must use
the same key in order to connect with this device. Check the table below for
instructions when entering the key.
Format Minimum
characters
Maximum
Characters
ASCII 8 63
Hexadecimal 8 64
= WPA Group Rekey Interval: Specifies the timer the WPA key must change. If the
value set 0, no need to change. The change is done automatically between the
server and the client.
= WPA Encryption: Select TKIP, AES or TKIP + AES. The TKIP is default. The TKIP +
AES encryption mode means AP auto adjust to use TKIP or AES according to
wireless clients.
Click Save/Apply to save the wireless security options and make the modification effect.
