DSL-2730E User Manual
The following table describes the parameters of this page.
Field Description
The virtual path identifier of the ATM PVC.
The virtual channel identifier of the ATM PVC.
QoS The QoS category of the PVC
. You can choose
UBR, CBR, rt-VBR, or nrt-VBR.
PCR Peak cell rate (PCR) is the maximum rate at which
cells can be transmitted along a connection in the
ATM network. Its value ranges from 1 to 65535.
CDVT Cell delay variation tolerance (CDVT) is the amount
of delay permitted between ATM cells (in
Its value ranges from 0 to
4294967295.
SCR Sustained cell rate (SCR) is the maximum rate that
traffic can pass over a PVC without the risk of cell
loss. Its value ranges from 0 to 65535.
MBS Maximum burst size (MBS) is the maximum number
of cells that can be transmitted at the PCR. Its value
3.2.3.3 ADSL Settings
Choose Setup > Internet Setup > ADSL Settings. The ADSL Settings page
appears. This page contains a modulation and capability section to be specified
by your ISP. Consult with your ISP to select the correct settings for each. Click
Apply Changes to finish.
29
