DSL-2730E User Manual
3.3.2 Access Control List
Multiple connections are required by some applications, for example, internet
games, video conferencing and Internet telephony. These applications have
difficulties working through NAT (Network Address Translation). This section is
used to open multiple ports or a range of ports in your router and redirect data
through those ports to a single PC on your network.
3.3.2.1 Access Control List
Choose Advanced > Access Control List > Access Control List. The page
shown in the following figure appears. In this page, you can permit the data
packets from LAN or WAN to access the router. You can configure the IP address
for Access Control List (ACL). If ACL is enabled, only the effective IP address in
the ACL can access the router.
Note:
If you select Enable in ACL capability, ensure that your host IP address is in
ACL list before it takes effect.
43
