DSL-2730E User Manual
Field Description
Add Click it to add the RIP interface to the Rip Config
List.
Delete Select a row in the Rip Config List and click it to
delete the row.
3.3.13 N AT
Under this menu, NAT ALG (Application Layer Gateway), NAT Exclude IP, NAT
Forwarding, FTP ALG Config and NAT IP Mapping can be performed.
3.3.13.1 NAT ALG
Choose Advanced > N AT > N AT AL G . The NAT ALG and Pass-Through page
shown in the following figure appears. Choose the NAT ALG and Pass-Through
options, and then click Apply Changes.
3.3.13.2 NAT Exclude IP
Choose Advanced > N AT > NAT Exclude IP. The NAT EXCLUDE IP page
shown in the following figure appears. In the page, you can configure some
source IP addresses which use the purge route mode when accessing the
Internet through the specified interface.
76
