D-Link DSL-2730E User Manual

DSL-2730E User Manual
Field Description
to the Current ACL Table.
Reset
Click it to refresh this page.
When the direction of data packets is set to WAN, the page shown in the
following figure appears.
The following table describes the parameters and buttons of this page:
Field Description
Direction Select
Select the router interface. You can select LAN or
WAN. In this example, WAN is selected.
WAN Setting
You can choose Interface or IP Address.
WAN Interface
Choose the interface that permits data packets from
WAN to access the router.
45

D-Link DSL-2730E Specifications

General

Brand	D-Link
Model	DSL-2730E
Category	Network Router
Language	English
