D-Link DSL-2730E User Manual

DSL-2730E User Manual
LED
Color
Status
Description
WLAN
Green
Blinks
Data is transmitted through the WLAN
interface.
On
The connection of WLAN interface is
normal.
Off The WLAN connection is not established.
WPS
Blue
Blinks
WPS negotiation is enabled, waiting for
the clients.
Off
WPS negotiation is not enabled on the
device.
DSL
Green
Off
Initial self-test is failed.
Blinks
The device is detecting itself.
On
Initial self-test of the unit has passed and
is ready.
Internet
Green
Off
The device is under the Bridge mode,
DSL connection is not present, or the
power is off.
Blinks
Internet data is being transmitted in the
routing mode.
On
IP is connected.
Red On
The device is attempted to become IP
connected, but failed.
Rear Panel
Figure 2 Rear panel
3
