DSL-2730E User Manual
Click add rule to add it to the QoS Rule List.
3.3.11.4 UpnP
UPnP (Universal Plug and Play) is a networking architecture that provides
compatibility among networking equipment, software, and peripherals. This
router has optional UPnP capability, and can work with other UPnP devices and
software. The system acts as a daemon when you enable UPnP. Leave the
UPnP option enabled as long as the LAN has other UPnP applications.
Choose Advanced > Network Tools > UPnP. The UPnP Configuration page
shown in the following figure appears.
Field Description
QoS Policy You can choose stream based, 802.1p based, or
You can choose strict prior or WFQ (4:3:2:1).
The IP address of the source data packet.
The subnet mask of the source IP address.
The IP address of the destination data packet.
The subnet mask of the destination IP address.
The port of the source data packet.
The port of the destination data packet.
Protocol The protocol responding to the IP QoS rules. You can
choose TCP, UDP, or ICMP.
The LAN interface responding to the IP QoS rules.
Set priority The priority of the IP QoS rules. P0 is the highest
priority and P3 is the lowest.
You can choose from 0 to 7.
Delete Select a row in the QoS rule list and click it to delete
Delete all Select all the rows in the QoS rule list and click it to
