DSL-2730E User Manual
Field
Description
Enable SNMP
Select it to enable SNMP function. You need to
enable SNMP, and then you can configure the
parameters of this page.
Trap IP Address
Enter the trap IP address. The trap information is
sent to the corresponding host.
Community Name
(Read-only)
The network administrators must use this password
to read the information of this router.
Community Name
(Read-Write)
The network administrators must use this password
to configure the information of the router.
3.3.11.6 TR-069
TR-069 is a WAN management protocol. It is a bidirectional SOAP/HTTP based
protocol providing the communication between the ADSL router and an Auto
Configuration Server (ACS) to monitor status and performance and to set
configuration parameters from WAN side.
Choose Advanced > Network Tools > TR-069. The TR-069 Configuration
page shown in the following figure appears. You may change change the setting
for the ACS's parameters.
