DSL-2730E User Manual
Field Description
Select it to use static IP routes.
Enter the IP address of the destination device.
Enter the subnet mask of the destination device.
Next Hop Enter the IP address of the next hop in the IP route to the
The metric cost for the destination.
The interface for the specified route.
Add Route Click it to add the new static route to the Static Route
Update Select a row in the Static Route Table and modify the
parameters. Then click it to save the settings temporarily.
Select a row in the Static Route Table and click it to
Show
Routes
Click it, the IP Route Table appears. You can view a list
of destination routes commonly accessed by your
A list of the previously configured static IP routes.
Click Show Routes, the page shown in the following figure appears. The table
shows a list of destination routes commonly accessed by your network.
73
