D-Link DVG-5402G

DVG-5402G/GF Wireless AC1200 MU-MIMO Dual Band
Gigabit Router with Fiber WAN Port, 3G/LTE Support, 2 FXS
Ports, and USB Port
User Manual
Configuring via Web-based Interface
IPv6
Go to the IPv6 tab to change or add the IPv6 address of the router, configure IPv6 addresses
assignment settings, specify MAC address and IPv6 address pairs, or add own DNS records.
Figure 98. Configuring the local interface. The IPv6 tab. The Local IPv6 Address section.
To add an IPv6 address of the router, click the ADD button ( ). To change the IPv6 address of
the router, select it in the table.
Figure 99. Configuring the local interface. The IPv6 tab. The window for adding an IPv6 address.
In the opened window, you can specify the following parameters:
Parameter Description
Local IPv6 Address
IPv6 address
The IPv6 address of the router in the local subnet.
Prefix
The length of the prefix subnet.
Gateway IPv6 address
Available if the Access point, Repeater, or Client mode was
selected in the Setup Wizard.
The gateway IPv6 address which is used by the router to connect to
the Internet (e.g., for synchronizing the system time with an NTP
server). Optional.
Click the APPLY button.
To remove the IPv6 address, select the checkbox located to the left of the relevant line in the table
and click the DELETE button ( ). Then click the APPLY button. Also you can remove the IPv6
address in the editing window.
Page 120 of 311
