D-Link DVG-5402G

DVG-5402G/GF Wireless AC1200 MU-MIMO Dual Band
Gigabit Router with Fiber WAN Port, 3G/LTE Support, 2 FXS
Ports, and USB Port
User Manual
Configuring via Web-based Interface
You can specify the following parameters:
Parameter Description
Enable
Move the switch to the right to enable the EoGRE tunnel.
Move the switch to the left to disable the EoGRE tunnel.
Name
A name of the tunnel for easier identification. You can specify any
name.
Remote IP address
The IP address of the remote local subnet.
Tagged
Move the switch to the right to assign a tag (VLAN ID) to EoGRE
traffic and specify the needed value in the VLAN ID field displayed.
Interface
From the drop-down list, select a WAN connection through which
the tunnel will pass. Select the Default gateway value to use the
default WAN connection.
MTU
The maximum size of units transmitted by the interface.
After configuring all needed settings, click the APPLY button.
To edit the parameters of an existing tunnel, in the Tunnels section, select the relevant tunnel in the
table. On the opened page, change the needed parameters and click the APPLY button.
To remove an existing tunnel, select the checkbox located to the left of the relevant line in the table
and click the DELETE button ( ).
VPN tunnels using EoGRE technology will appear in the Default group on the Advanced /
Interface Grouping page and will be automatically removed from this group after the tunnel is
deleted from the current page.
Page 142 of 311
