D-Link DVG-5402G

DVG-5402G/GF Wireless AC1200 MU-MIMO Dual Band
Gigabit Router with Fiber WAN Port, 3G/LTE Support, 2 FXS
Ports, and USB Port
User Manual
Configuring via Web-based Interface
Parameter Description
Support rport
Move the switch to the right to enable the Symmetric Response
Routing function in accordance with RFC3581. This function allows
sending responses to a request to the port and IP address from which
the request was received via the NAT-enabled router. The SIP proxy
server must support the function.
Save log to a USB
storage
Move the switch to the right to save the call log to a USB storage
connected to the router. Upon that the Path and File name fields
are displayed on the page.
Path
Click the Search icon ( ) located to the right of the field in order
to locate the folder where call log files will be stored.
File name
A name for call log files.
NAT Traversal
Mode
The NAT Traversal function allows VoIP traffic to pass through the
NAT-enabled router.
Select the Disabled value to disable the function.
Select the STUN value to enable the STUN client (Session
Traversal Utilities for NAT). The STUN client sends requests to a
STUN server. On the basis of the received replies, the client allows
VoIP traffic to pass through the NAT-enabled router. When this value
is selected, the Server address, Port, and Binding period fields
are displayed.
Select the NAT Public IP value to manually specify a public
(“white”) IP address of an upper-level router which exchanges
service messages with the SIP proxy server. When this value is
selected, the Public address and Port fields are displayed.
Server address
An IP or URL address of a STUN server to which a connection is
established.
Public address
A public (“white”) IP address of an upper-level router which
exchanges service messages with the SIP proxy server.
Page 228 of 311
