DVG-5402G/GF Wireless AC1200 MU-MIMO Dual Band
Gigabit Router with Fiber WAN Port, 3G/LTE Support, 2 FXS
Ports, and USB Port
User Manual
Configuring via Web-based Interface
In the opened window, you can specify the following parameters:
Parameter Description
Event
Select the needed value from the drop-down list.
• AlertInfo: Allows to change the phone ring type according
to special ISP’s data specified in the Template field.
• CallerID: Allows to change the phone ring type according to
special ISP’s data specified in the Phone field.
Phone
The phone number of the calling party. Contact your ISP to clarify
the number format. The field is displayed if the CallerID value is
selected in the Event drop-down list.
Template
The value of CallerID information field transmitted by your ISP in
SIP packets. Contact your ISP to clarify the template format. The
field is displayed if the AlertInfo value is selected in the Event
drop-down list.
Ring
Select a ring for the event from the drop-down list.
After specifying the needed parameters, click the SAVE button.
To edit the parameters of an existing event, in the Event list section, select the corresponding line
in the table. In the opened window, change the needed parameters and click the SAVE button.
To remove an existing event, select the checkbox located to the left of the relevant line in the table
and click the DELETE button ( ). Only events created by the user can be deleted.
After specifying the needed parameters, click the APPLY button.
Page 241 of 311
