D-Link DVG-5402G

DVG-5402G/GF Wireless AC1200 MU-MIMO Dual Band
Gigabit Router with Fiber WAN Port, 3G/LTE Support, 2 FXS
Ports, and USB Port
User Manual
Configuring via Web-based Interface
Parameter Description
Logging
Type
Select a type of logging from the drop-down list.
• Local: The system log is stored in the router's memory. When
this value is selected, the Server and Port fields are not
displayed.
• Remote: The system log is sent to the remote host specified
in the Server field.
• Remote and local: The system log is stored in the router's
memory and sent to the remote host specified in the Server
field.
Level
Select a type of messages and alerts/notifications to be logged.
Server
The IP or URL address of the host from the local or global network,
to which the system log will be sent.
Port
A port of the host specified in the Server field. By default, the value
514 is specified.
Record to USB
USB Storage
If a USB storage is connected to the router, its name is displayed in
the field.
To safely disconnect the USB storage, click the UNMOUNT button.
Save log to a USB
storage
Move the switch to the right so that the device could send the system
log to the USB storage connected to it. Upon that the Path, File
name, The maximum size of one file, and Number of files
to keep fields are displayed.
Path
Click the Search icon ( ) located to the right of the field in order
to locate the folder where system log files will be stored.
File name
A name for system log files.
The maximum size of
one file
The maximum size (in kilobytes) of one system log file.
Number of files to keep
The maximum number of files allowed to be recorded on the USB
storage. When this number is exceeded, the file containing the oldest
data will be deleted. The field is available for editing if the value
specified in the The maximum size of one file field is greater
than zero.
After specifying the needed parameters, click the APPLY button.
Page 286 of 311
