D-Link DWR-932C User Manual

79D-Link DWR-932C User Manual
Appendix B - Networking Basics
Statically Assign an IP address
Step 2
Right-click on the Local Area Connection which represents your network adapter and select Properties.
Step 3
Highlight Internet Protocol (TCP/IP) and click Properties.
Step 4
Click Use the following IP address and enter an IP address that is on the same subnet as your network
or the LAN IP address on your router.
Example: If the router´s LAN IP address is 192.168.0.1, make your IP address 192.168.0.X where X is a
number between 2 and 99. Make sure that the number you choose is not in use on the network. Set
Default Gateway the same as the LAN IP address of your router (192.168.0.1).
Set Primary DNS the same as the LAN IP address of your router (192.168.0.1). The Secondary DNS is not
needed or you may enter a DNS server from your ISP.
Step 5
Click OK twice to save your settings.
Click on Start > Control Panel > Network and Internet Connections > Network Connections > Congure your Internet
Protocol (IP) settings.
Step 1
If you are not using a DHCP capable gateway/router, or you need to assign a static IP address, please follow the steps below:
Windows
®
8
Windows
®
7
Windows
®
Vista
™
Windows
®
XP
Click on Start > Control Panel > Network and Internet > Network and Sharing Center > Manage Network Connections.
Click on Start > Control Panel > Network and Internet > Network and Sharing Center > Manage Network Connections.
Click on Start > Control Panel > Network Connections.

D-Link DWR-932C Specifications

General

Model	DWR-932C
Category	Wireless Router
Frequency Band	2.4 GHz
SIM Support	Yes
Battery Capacity	2000 mAh
Security	WPA/WPA2
Wireless Speed	Up to 150 Mbps
Cellular Technology	4G LTE
Antennas	Internal
Wireless Standard	802.11n
Interfaces	Micro-USB
Weight	77 g
