D-Link Nuclias Connect DAP-2610 User Manual

D-Link DAP-2610 User Manual
7
Hardware Overview
LED Connections
2 Power Receptor Connect the supplied power adapter.
3 LAN (PoE) Port
Connect to a Power over Ethernet (PoE) switch or router via
an Ethernet cable.
4 Reset Button
Press and hold for ve seconds to reset the access point to
the factory default settings. Press and hold for one second
to reboot the access point.
1 Power/Status
Solid Red Indicates the access point has malfunctioned.
Blinking Red This LED will blink during boot-up.
Solid Green
Indicates that the DAP-2610 is working
properly.
1

D-Link Nuclias Connect DAP-2610 Specifications

General

Wireless Standard	IEEE 802.11a/b/g/n/ac
Frequency Band	2.4 GHz, 5 GHz
Antenna Type	Internal
PoE Support	802.3af PoE
Management	Nuclias Connect
Operating Humidity	10% to 90% non-condensing
Ethernet Ports	1 x Gigabit Ethernet
Security	WPA/WPA2
Operating Modes	Access Point, Wireless Distribution System (WDS), WDS with AP, Wireless Client
Mounting	Wall, Ceiling
Operating Temperature	0 to 40 °C
