D-Link DAP-2622 User Manual
7
Hardware Overview
LEDs Connections
2 LAN (PoE) Port
Connect to a Power over Ethernet (PoE) switch or router via
an Ethernet cable.
3 Lan (PoE Out) Port Gigabit RJ-45 port for data and PSE out.
4 Ethernet LAN Port Gigabit RJ-45 port for data.
5 Reset Button
Press and hold for ve seconds to reset the access point to
the factory default settings. Press and hold for ten seconds
to reboot the access point.
1 Power/Status
Solid Red Indicates the access point has malfunctioned.
Blinking Red This LED will blink during boot-up.
Solid Green
Indicates that the DAP-2622 is working
properly.
1
3
4
5
2
