Method 2 - PoE without PoE Switch or Router
1. Connect one end of an Ethernet cable into the Data In port on the PoE base unit
(not included) and the other end into one port on your switch, router, or computer.
2. Connect one end of an Ethernet cable into the P+Data Out port on the PoE base
unit and the other end into the LAN (PoE) port on the access point.
3. Use the supplied power adapter. Connect the power adapter to the Power In
receptor on the PoE adapter.
4. Connect the power cable to the power adapter and then connect the other end
into a power outlet.
5. Enter dap2622.local in the address eld of your browser.
6. Log in to the Administration Web pages. The default login information is:
Username: admin
Password: admin
DAP-2622
Switch or Router
PC
Power Adapter
PoE Adapter
