xStack
®
DES-3200-10/18/28/28F Layer 2 Ethernet Managed Switch User Manual
Figure 5 - 9. Port Security Port Settings window
The following parameters can be set:
Parameter Description
From Port/To Port
A consecutive group of ports may be configured starting with the selected port.
Admin State
This pull-down menu allows you to enable or disable Port Security (locked MAC address table
for the selected ports).
Max. Learning
Address (0-64)
The number of MAC addresses that will be in the MAC address-forwarding table for the
selected switch and group of ports.
Lock Address
Mode
This pull-down menu allows you to select how the MAC address table locking will be
implemented on the Switch, for the selected group of ports. The options are:
Permanent – The locked addresses will not age out after the aging timer expires.
Delete on Timeout – The locked addresses will age out after the aging timer expires.
Delete on Reset – The locked addresses will not age out until the Switch has been
reset.
Click Apply to implement changes made.
121
