D-Link xStack DES-3200-10 User Manual

xStack
®
DES-3200-10/18/28/28F Layer 2 Ethernet Managed Switch User Manual
Figure 3 - 27. IGMP Snooping Router Ports Settings window
Select the desired member ports and click Apply. Click <<Back to go back to the IGMP Snooping Settings window.
IGMP Access Control Settings
This window is used to configure IGMP Access Control settings on the Switch.
To view this window, click L2 Features > IGMP Snooping > IGMP Access Control Settings:
Figure 3 - 28. IGMP Access Control Settings window
Parameter Description
From Port/To Port
Select a range of ports.
State
Enable or disable the IGMP Access Control. When Enable is selected and the Switch receives
an IGMP Join request, the Switch will send the access request to the RADIUS server to do the
authentication.
Click Apply to implement changes made.
80
