DES-3200-10/18/28/28F Layer 2 Ethernet Managed Switch User Manual
Non-SIM devices
Tool Tips
In the Topology view window, the mouse plays an important role in configuration and in viewing device information.
Setting the mouse cursor over a specific device in the topology window (tool tip) will display the same information
about a specific device as the Tree view does. See the window below for an example:
Figure 2 - 45. Device Information Utilizing the Tool Tip
Setting the mouse cursor over a line between two devices will display the connection speed between the two devices,
as shown below:
Figure 2 - 46. Port Speed Utilizing the Tool Tip
