xStack
®
DES-3200-10/18/28/28F Layer 2 Ethernet Managed Switch User Manual
Figure 7 - 11. Transmitted (Tx) window (for Bytes and Packets)
To view the Transmitted (Tx) Table window, click the link View Table
.
Figure 7 - 12. Transmitted (Tx) Table window (for Bytes and Packets)
The following fields may be set or viewed:
Parameter Description
Port
Use the drop-down menu to choose the port that will display statistics.
Time Interval
Select the desired setting between 1s and 60s, where "s" stands for seconds. The default
value is one second.
Record Number
Select number of times the Switch will be polled between 20 and 200. The default value is
200.
Bytes
Counts the number of bytes successfully sent on the port.
192
