(1) 2
nd
Thrower Cleaning Port
(2) 1
st
Bevel Case Cleaning Port
(3) 1 Spiral box clean-out opening
1. Idle the threshing unit for 3 min-
utes
2. Open the straw cutter (refer to
8-16).
3. Dismantle the vibrating sieve
(refer to 8-20).
4. Close the cutter unit.
5. Open the threshing compart
-
ment
6. Remove the reaping unit.
7. Remove the grain sieve.
8. Open the 2
nd
thrower cleaning
port, 1
st
auger (interior), 1
st
au-
ger case cleaning port, 2
nd
au-
ger case cleaning port, inspec-
tion window, and 1
st
bevel case
cleaning port. Then, clean the
inside.
4. Dry up t he insid e of the
combine before cleaning up
the inside. If the inside is
wet, grains can get caught
inside.
5. Securely fasten the port cov
-
er after each cleanup. Other-
wise, grains may scatter.6.
Remove any straw debris
left inside the blower shaft.
7. After threshing a wet crop,
you must clean up the 1
st
auger case unit.
