Daedong DSC62 - Periodical Lubricating Points

8-30 DSC62
417O827A 417O828A
GREASE ON THE ONE-WAY
CUTTING CLUTCH
When dissembled, add grease
into the cam clutch and on the ball
bearings.
(1) Cam Clutch
OIL IN CHAIN DRIVE CASE
Removethellingplugandcheck
the amount of oil.
(1) Filling Plug
Oil Capacity
Gear oil #90 or #80
DAEDONG TF55
0.3ℓ
The (

) marked points are lubri
-
cated by a centralized oiling sys-
tem.
PERIODICAL LUBRICAT-
ING POINTS
When adding oil, secure the
cuff and do not wear loose
jacket, with no hand towel
tied around waist or neck
to prevent being caught by
chains.
Please keep appropriate
distance in order to avoid
contact between oil feeder
and chain at oil adding.
•
•
SAFETY RULES
