8-46 DSC62
(1) Straw Discharge Plant Side Chain
(A) Less than 3 mm
417O872A 417O873A417O871A
ADJUSTING THE FEEDING
DEPTH CHAIN
(1) Depth Chain (3) Fixing Nut
(2) Adjusting Nut
(1) Fixing Nut (3) Clearance 1 ~ 2 mm
(2) Adjusting Bolt
STRAW DISCHARGE PLANT
SIDE CHAIN
Extrusion size of
the spacer (A)
Less than
3 mm
Clearance
1~2mm
