DAELIM NS125III

Front Wheel/Front Fork/Steering
Front Wheel
Removal
● Loosen axle nuts. Support bottom of engine with
a jack until the front wheel is lifted.
● Remove screws from the speedometer gear box,
and separate the speedometer cable. Remove axle
nuts, front axle, and front wheel.
NOTE
12-5
󳢯 Do not operate brake lever after the front wheel
is removed.
Rear handle cover
Front handle cover
Speedometer cable
Speedometer gear box
Axle nut
Screw
● Insert the brake cable, speedometer cable, throttle
cable into the handle cable guide.
●
Install the rear handle cover to the steering handle.
● Connect the speedometer cable, and tighten cable
nut completely.
●
Lift the front handle cover, and connect the winker
wiring.
● Insert the front handle cover into the rear handle
cover joint (hook type), and tighten with screws.
NOTE
● Install the LH. RH. front handle side cover.
● Install the front cover. (󳫻 4-3)
● Install the back mirror.
󳢯 Make sure the front wiring is not interfered with.
