Front Wheel/Front Fork/Steering
● Remove the top cone race, steel ball, and steering
stem.
NOTE
● Check the steel ball, cone race, and ball race for
wear or damage. Replace worn or damaged ones.
● Remove the steering bottom cone race, dust seal,
dust seal washer.
● Remove the top ball race and the bottom ball race
into the steering head pipe.
Tool: Ball race driver
Assembly
● Insert the top ball race and the bottom ball race
into the steering head pipe.
Tools: Driver
Attachment 37
××
40mm
12-16
Place steel balls in a pan to prevent from being lost.
Top cone race
Steel ball
Steering bottom
cone race
Dust seal
To Next Page
